Manufacturing Technology Lab (MTL) is equipped with general and special purpose precision lathes, Milling and boring machines, electro-discharge machining facilities and grinding machines. These machines are capable of machining precision components with high dimensional accuracy and fine surface finish.
The planning activities are carried out using “Manufacturing Enterprise Resource Planning Software” which tries to synchronize user expectations with available resources so that the manufactured job meets the quality requirements. The coordination of all activities is done by dedicated coordination team in MTL.
All machines and computers are connected through a dedicated internal network to ease data transfer, code transfer, visualization and monitoring.
Maintenance of all machines is also done by MTL. MTL follows Operate, Maintain and Deliver.
1 |
5-Axes Machining Centre |
2 |
Hollow Spindle Lathe |
3 |
Jig Boring Machine |
4 |
UP-65 Turn Mill Centre |
5 |
4-Axes- CNC Horizontal Boring Machine |
6 |
CNC Vertical Turret Lathe |
7 |
LAL 2B CNC Lathe |
8 |
PILATUS 25 T CNC Lathe |
9 |
SMART TURN CNC Lathe |
10 |
LX20T L7 CNC Lathe |
11 |
4-Axes–CNC Horizontal Machining Centre |
12 |
3-Axes CNC Milling Machine |
13 |
4-Axes CNC Universal Milling Machine |
14 |
4-Axes Horizontal Machining Centre |
15 |
3-Axes CNC Machining Centre |
16 |
Surface Grinding Machine |
17 |
Precision Surface Grinding |
18 |
CNC EDM Flush Type Wire Cut Machine |
19 |
Advanced VTL with Live Tool Machine |
20 |
CNC Chucker Lathe |
21 |
CNC Star Turn Lathe |
22 |
Electric Discharge Die-Sinker-Machine |
23 |
Electric Discharge Drilling Machine |
24 |
Wire Cut ED Machine |
25 |
Submersible type 4-1/2 Axis Precision CNC wire cut EDM |
26 |
CNC Drill Tap Centre (HSTC) |
27 |
CNC Drill Tap Centre (VMC) |
28 |
Radial Drilling Machine (RM-65)-1 |
29 |
Radial Drilling Machine (RM-65)-2 |
30 |
Swing Radial Drilling Machine |
31 |
Bench Drilling Machine |
32 |
Hydraulic Plate Shearing machine with NC Back Gauge |
33 |
Mechanical Shearing Machine |
34 |
Horizontal Band Saw Machine-1 & 2. |
35 |
Vertical Band Saw Machine |
36 |
Hydraulic Press |
37 |
Plate Bending Machine |
38 |
Press Brake |
39 |
CNC Water Jet Cutting Machine |
40 |
Air Plasma Cutting Machine |
41 |
ACCUTIG (Inverter Type) AC/DC TIG Welding Machine |
42 |
REHM 330 INVERTIG AC/DC TIG Welding Machine |
43 |
Memco Welding Machine |
44 |
Paint Shop |
